Home > 1000WOG Threaded Ball Valve >

penumatic ball valve/ motorized ball valve

Product Categories
STV Valve Technology Group Co.,Ltd
Contact Now

penumatic ball valve/ motorized ball valve

Place of Origin : china

Brand Name : stv

Model Number : stv-0667

Standard or Nonstandard : Standard

Structure : Ball

Pressure : Low Pressure

Power : Pneumatic

Material : Casting

Temperature of Media : Normal Temperature

Media : Water

Port Size : 100

MOQ : 1

Price : 10USD

Packaging Details : standard export packing

Delivery Time : stocks

Payment Terms : T/T

Supply Ability : 10000pcs/month

Contact Now

1. Construction is as follows:
- Stainless Steel Ball Valve
- Full Port or Reduce Port
- Split Body
- Bolted Bonnet with spiral-would gasket
- Fire Safe Design
- Anti-static Design & Blow-out proof stem
- Double seat structure
- Butt Weld Ends to ASME B16.25
- Flanged Ends to ASME B16.5

2. Main Part & Materials

Part Names Part Materials
Body CF8/F304 CF8M/F316 CF3/F304L CF3M/F316L
Bonnet CF8/F304 CF8M/F316 CF3/F304L CF3M/F316L
Ball SS304 SS316 SS304L SS316L
Stem F304 F316 F304L F316L
Seat/Seat Ring SS304 SS316 SS304L SS316L
Packing Graphite/PTFE
Gasket SS304+Graphite/SS304+Graphite
Bolts/Nuts B8/8 B8M/8M B8/8 B8M/8M
Suitable Medium HNO3, CH3OOH etc.
Suitable Temperature -196~427 °C -196~427 °C -196~427 °C -196~427 °C


3. Normal Pressure Rating
PN10~PN420, CLASS150~2500

4. Normal Size Range
DN50~DN1000, 2"~40"
